Viessmann 7498529 Insulated Low-Loss Header - 1.25" NPT, 19.5 GPM - 7498529
Viessmann
$521.54
$814.90
(You save
$293.36
)
Write a Review
Viessmann
Viessmann 7498529 Insulated Low-Loss Header - 1.25" NPT, 19.5 GPM - 7498529
When used in conjunction with the Vitodens 100, or Vitodens 200, boilers, the low-loss header acts as a hydraulic break, decoupling boiler and system circuits from each other. It is recommended to use the low-loss header in applications in which the total system flow rate exceeds the maximum boiler flow rate. Viessmann strongly recommends the use of a low-loss header in cases where the system head and flow rates are unknown. The temperature sensor connection located at the top of the low-loss header ensures low return temperatures to the Vitodens 200, boilers, at all times, increasing operational efficiency. In addition, the low-loss header helps eliminate air and debris from the heating system.
LLH Model: Type 80/60
Connector Size (NPT): 1.25"
Maximum Flow Rate: 19.5 GPM
Compatible with Vitodens 100/200 Boiler Models (Please note that the temperature sensor for Vitodens 200, WB2A/B must be purchased separately)
Includes matching insulation box
LLH Model: Type 80/60
Connector Size (NPT): 1.25"
Maximum Flow Rate: 19.5 GPM
Compatible with Vitodens 100/200 Boiler Models (Please note that the temperature sensor for Vitodens 200, WB2A/B must be purchased separately)
Includes matching insulation box
