Samlex - Transfer Switch 30a - STS-30

Samlex - Transfer Switch 30a - STS-30

Samlex
UPC:
622988079306
$294.40
$367.90
(You save $73.50 )
Current Stock:
Adding to cart… The item has been added
Description
SamlexPower STS-30 30A Transfer Switch

Connect a Samlex Transfer Switch to your generator or Utility Power and Inverter; or Generator and Inverter
  • Has rated capacity of 30 Amps at 120 VAC and is suitable for 30 Amp Utility Power Cord and Generator of up to 3.6 KVA capacity

  • Uses heavy duty Double Pole Double Throw (DPDT) relay for switching both the Line and Neutral

  • Can be installed on the line side of the main breaker panel allowing switching of the entire load or on the load side to only switch dedicated circuits

  • DIP Switch select to enable time delay of 20 to 25 sec when transferring to a generator

  • Comes with a standard North American power cord for convenient connection to 15 Amp NEMA5-15R receptacles on a generator or an inverter with up to 1800 VA capacity (Replace this cord with 30 Amp cord if full 30 Amp capacity is required)

  • NEMA5-20R Duplex Receptacle for convenient connection of battery charger


    • Rating : 120V& 30A
    :
    :
    :
    :
    :
